Automatic Surface Tensiometer, DyneMaster DY-500

    40,516.00 40,516.00 40516.0 USD


    This combination does not exist.

    Add to Cart

    DY-500 DyneMaster Automatic Tensiometer
    High-end surface tensiometers that perform measuring dynamic contact angle and powder contact angle, lamella length and liquid density in addition to surface/interfacial tension (Wilhelmy plate or DuNouy Ring).

    ◆ Fully automatic operation by single command button.
    ◆ Built-in stirrer functions in the sample stage.
    ◆ Dynamic contact angle (advancing/receding angle) measurement by Wilhelmy method (Option of DY-700)
    ◆ Powder contact angle measurement to evaluate wetting phenomena of powder samples (Option of DY-700/500)
    ◆ Automatic Critical Micelle Concentration (CMC) of surface tension (Option of DY-700/500)
    ◆ Built-in surface thermometer (for heated/chilled samples requires electronic heater option or heater/chill bath option)
    ◆ Lamella length measurement
    ◆ Liquid density measurement by pycnometer

    Measurement methods:
    • Surface/interfacial tension
    • Powder contact angle & wetting speed
    • Lamella length measurement,
    • Liquid density measurement (Pycnometer)

    • Measurement range of S.T.: 0~100 mN/m *Balance capacity & displaying range: 0~1000mN/m
    • Measurement accuracy*: 0.2 mN/m
    • Resolution: 0.01 mN/m
    • Stage speed, stroke: 0.002~50 mm/s, 50mm
    • Standard measurement unit: Platinum plate or Platinum DuNouy Ring
    • Optional measurement unit & kit: Platinum ring, Density measurement kit, Dynamic contact angle measurement kit, Powder contact angle measurement kit, CMC Kit
    • Measurement temperature: Ambient~150°C (Heater type), 10~70°C (Jacket type)
    • External dimensions: 295(W) x 415(D) x 452(H)mm
    • Weight: About 20kg
    • Electric power: AC100-240~50/60Hz
