KDCU-551H Auto Cleaning and Sampling Unit

KDCU-551H Auto Cleaning and Sampling Unit with a heater option (Room Temp. ~ 80°C)

- Model name: DCU-551 Auto Clean and Sampling Unit
- Type: Standard and Small size sampling
- Sample vial: 20mL vial and or 8mL vial
- Required sample: 10mL and 5mL (General-purpose concentration meter : 6mL)

- Sampling method: Pressurizing
1) Drain sample by pressurized pumping
2) Return a sample by the sample-back system

- Drain method
1) Drain sample by pressurized pumping
2) Return a sample by the sample-back system

-Control
1) Auto start with [Meas.] key on a measuring unit
(General-purpose concentration meter, Density/specific gravity meter or Refractometer)
2) Auto start with [Start] key on the Main unit
3) Rinse and purge
4) Auto calibration with [Calib.] key on a measuring unit
(General-purpose concentration meter, Density/specific gravity meter, Refractometer)

-Display: 20 digits by 2 lines LCD with a backlight

-External communication: With a measuring unit: Simplified serial interface With a unit in general: RS-232C × 1 ch.

-Ambient conditions
Temperature : 5 to 35°C (Note: When the ambient temperature is below 15°C, use Acetone for “Rinse 2” solution)
Humidity : Below 85%RH (subject no condensation)

-Power Source: AC 100-120 / 200-240 V ±10%, 50/60 Hz
-Power Consumption: Max. 760W (Main unit Approx. 40W)
-Dimensions: W(291) × D(310) × H(342) [mm]
-Weight: Approx. 10kg
-CE marking: EMC : EN61326 LVD : EN61010-1 conformed
