Viscosity range for RM100 CP1000/CP2000: 2 to 5,000,000 mPa.s
Cone diameter 40mm / Cone angle 0.5°
FEATURES
Measuring systems cone or plate compatible with DIN 53019 / ISO 3219 / ASTM D4278-D7395 (316L Stainless Steel) enable setting shear rate in order to carry out viscosity measurements or to obtain curves to study flow behavior, yield stress and thixotropy.
Particularly suitable for measurements on very small quantities for control or development of homogeneous products with or without particles (size <100μm).
AC 265 coupling enables quick setup of the measuring system, better maintenance and increased repeatability.
NOTE: Compatible only with CP2000 / CP4000 instruments.

Anchor-type measuring system (316L stainless steel). Bayonet coupling.
Includes:
- St-R Centring Tool (114436)
- MK-R3 spindle (114427)
- MB-3 sample cup (114314)

MK-CP 6010 Spindle for Cone-Plate Viscometers. Only compatible with RM100, RM200, or DSR500 Viscometers. Sample volume: 1mL. Shear rate range: 2 to 9000 s-1. Viscosity Range: 1-27000cP.

Measuring spindles according to ASTM / ISO 2555 (316L stainless steel). Bayonet Coupling.
These systems are ideally suited for simple viscosity measurement at controlled rotational speed in all areas of activity.
Use of 600ml beaker for measurement is recommended.

MK-R1-5 Spindle Set in Case. Anchor-type spindles.

Measuring Cone MK CP 6020 AC265 (Cone D60 Angle 2°)

MK-CP 4040 (cone D40 4°angle). Bayonet Fitting. Sample volume: 1.17mL. Viscosity Range for First Plus: 80-1,500,000 cP. Viscosity Range for RM100/RM200/DSR500: 14-1,800,000 cP.

MK-CP 2005 (cone D20 0.5°angle). Bayonet fitting. Sample volume: 0.018mL. Viscosity Range for First Plus: 80-1,500,000 cP. Viscosity Range for RM100/RM200/DSR500: 14-3,500,000 cP.

Spindle for Chocolate Viscosity Measurement.

MK-CP 2020 (cone D20 2°angle). Bayonet Fitting. Sample volume: 0.073mL. Viscosity Range for First Plus: 320-6,000,000 cP. Viscosity Range for RM100/RM200/DST500: 53-14,000,000

Width 21.7 mm Height 10 mm. Viscosity: 1000 - 10000 mPa.s

Width 21.7 mm Height 20 mm. Viscosity: 300 - 5000 mPa.s

Viscosity range for RM100/200/DSR500: 52 to 15.7 million mPa.s

MS VANE: Measuring spindles with blades (316L stainless steel).

Vane 71 spindle.

Set of ASTM/ISO 2555 spindles. Compatible with First Plus, RM 100 Plus and RM 200 Plus models. Not for portable instruments.

Measuring Bob R4 with Axis.

MS-R: Anchor-type measuring systems (316L stainless steel).
