Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 63 microns or No.230 : Sample Quantity is 5 x 0.25g.

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 90 microns or No.170 : Sample Quantity is 5 x 0.25g.

8-inch Diameter Stainless Steel Frame, Stainless Steel Mesh ASTM Sieve, 2.36mm or #8

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 300 microns or No.50 : Sample Quantity is 5 x 0.70g.

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 355 microns or No.45 : Sample Quantity is 5 x 0.70g.

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 425 microns or No.40 : Sample Quantity is 5 x 0.70g.

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 500 microns or No.35 : Sample Quantity is 5 x 0.70g.

Calibration standard for 100mm or 3" diameter sieves, NIST Traceable for 20 microns or No.25 : Sample Quantity is 5 x 0.25g.

INCLUDES:
• RheoTex software.
• Integrated temperature unit.
• Holder for disposable hook.
• Touch screen stylus.
• Calibration and checking certificate.
• User manual.
• Microfiber cloth.
• RS232/USB cable.

FEATURES: Direct control of temperature unit • Measure with disposable hooks and cups • Low sample volume • Display of viscosity limits according to spindle and speed

INCLUDES:
• Holder for disposable hook
• Integrated temperature unit
• Touch screen stylus
• User manual
• Calibration and checking certificate
• Microfiber cloth

INCLUDES:
• Holder for disposable hook
• Integrated temperature unit
• Touch screen stylus
• User manual
• Calibration and checking certificate
• Microfiber cloth

8-inch Diameter Stainless Steel Half-Height Frame, Stainless Steel Mesh ASTM 6.7mm or 0.265 inch

8-inch Diameter Stainless Steel Half-Height Frame, Stainless Steel Mesh ASTM Sieve, 250 micron or #60

Included:
• 2m cable between measuring head and box
• Touch screen stylus
• User manual
• Calibration and checking certificate
• Microfiber cloth

FEATURES: • Industrial measure on large tanker • Continuous measurement or with time to stop • 4-20 mA output for external control • 17m maximum distance between head and box • Usable with standard or rack stand • Huge viscosity range • Programming and recording methods • External temperature probe (option) • Printer connection • Display of viscosity limits according to spindle and speed

INCLUDES:
• 2m cable between measuring head and box
• Touch screen stylus
• User manual
• Calibration and checking certificate
• Microfiber cloth

FEATURES: • Industrial measure on large tanker • Continuous measurement or with time to stop • 4-20 mA output for external control • 17m maximum distance between head and box • Usable with standard or rack stand • Huge viscosity range • Programming and recording methods • External temperature probe (option) • Printer connection • Display of viscosity limits according to spindle and speed

Density/Specific Gravity Meter
ASTM D1250,D1475,D4052,D4806,D5002,D5798,D5931

-DI Support Feature as Standard
-Simultaneous multiple measurements
-Remote operation by a separated control terminal
-Improvement of the measurement cell visibility with a built-in camera

Configuration:
1. DA-860 main unit
2. Pump & Sampling unit type = 120799701/Sampling Unit with Accessories (Semiautomatic with 2 liquids)
3. Decoration panel = Stripe
4. Printer (mini) is NOT INCLUDED
5. Requires a computer (laptop or Surface Pro) = NOT INCLUDED
< Desktop/Laptop PC Spec >
OS.................................Windows® 10 Pro 64 bit
CPU..............................> = Core i3 10th Generation
Memory........................> = 8GB
HDD or SSD..................> = 300GB
Display Resolution.......> = 1280 x 768
Interface(LAN / USB)...> = 1000Mbps
< Tablet PC Spec >
OS.................................Windows® 10 Pro 64 bit
CPU.............................. > = Intel® Pentium® Gold 4425Y
Memory........................> = 4GB
HDD or SSD..................> = 64GB
Display Resolution.......> = 1280 x 768
Interface(LAN / USB)...> = USB3.0 x 1ch

Specifications:
-Measurement Method; Resonate Frequency Oscillation
-Measurement Range; 0 ~ 3 g/cm3
-Temperature Range; 0 ~ 100°C (32 ~ 212°F)
-Accuracy; Density; 0.00002
-Accuracy; Temperature; ±0.02
-Repeatability; SD 0.000001g/cm3
-Viscosity Correction: YES
-Min sample required; Approx. 1.0mL (by syringe), Approx. 2.0mL (by pump)
-Min Measurement Time; 1) Approx. 10 seconds (Manual)　*4
-Display;
1) Tablet / PC connection (LCD resolution: 1,280 x 800 or higher)
2) Shows density, SG, oscillation frequency, temp, concentration, other messages.
-Sampling;
1) Manual by syringe
2) Auto by pump
-Method; Saves up to 1000 different methods in built-in memory including measurement parameters, density auto-correction, concentration conversion, etc.
-Density Auto-Correction;
1) Saves conversion table or formula at your desired temperatures according to your samples.
2) Temperature conversion table preprogrammed according to ASTM standard for petroleum, petroleum products and lubricating oils.
-Auto Conversion;
1) Between concentration and density.
2) Between temperature and density.
-Statistics;
1) Auto or manual calculation of mean value, SD and coefficient.
2) Recalculation, data deletion.
-Interfaces;
1) LAN: × 1; Tablet / Personal computer (PC)
2) USB 2.0: × 1; USB flash drive, Thermal Printer (DP-600)*5
3) RS-232C: × 2; Dot Matrix Printer (IDP-100)*4, Autosampler (AS-8030)
-Options;
1) Printer: DP-600, IDP-100
2) 30 Position Autosampler: AS-8030
-Data I/O;
1) USB flash drive as data storage medium.
2) Application Notes provided in USB flash drive.
-Wetted Materials; PTFE, borosilicate glass, SUS304
-Ambient Condition;
1) Temperature: 5 to 35 °C (41 to 95 °F)
2) Humidity: 85%RH or below (No condensation allowed.)
-Power Supply; DC 24V 5A (Main Unit) AC 100 to 240 V ± 10%; 50/60 Hz (Comes with AC adapter.)
-Power Consumption; 40 W (max. 120 W, min. 20 W)
-Dimensions; 295 (W) × 330 (D) × 255 (H) mm (11.6 (W) × 13.0 (D) × 10.0 (H) inches)
-Weight; 19 kg (41 lbs)

- MAX Sample size : 400mm(W) x 150 mm(H) x ∞(D)
- 12x Zoom lens, USB3.0 type Digital CMOS camera
- 640x 480 Pixel resolution, Frame rate: Max 500 frame/sec
- Light source : White LED module ,Camera module tilting adjuster
- Contact angle measure range : 0-180 degree,±0.1deg Accuracy
- Surfaceware9 Software for static and dynamic contact angle &
Surface energy, Surface tension by Pendent drop method,
D-base function, Data comparing function, Exact drop volume calculator Auto avoid image noise of measuring, Analyzed data export to excel., etc Advanced.
“One drop” function, Able to measuring at the same time
Drop volume control by software(Per 0.1 μℓ by glass syringe)
- Standard accessories : Syringe (3ml:10ea), Needle(27G,22G:10ea/each ), Manual, Calibration images(30, 60, 120±0.5degree)
- USB connect to Desktop PC or Notebook (Window 7/8/10)
-Device dimension : 600mm(W)x160mm(D)x550mm(H

-Camera capture speed: 640x480resolution 500FPS (USB 3.0)

-Static Contact Angle (Tangent line method 1 & 2, Trigonometric function):
Accuracy; ±0.1degree
Resolution; ±0.01degree
Range; 0~180°
Data Information; Average contact angle, left contact angle, right contact angle, drop
volume, height, baseline length, base area, measured time, wetting energy, spreading
coefficient, work of adhesion

-Dynamic Contact Angle: Tilting method (OPTIONAL)
Accuracy; ±0.1degree
Resolution; ±0.01degree
Range; 0~90°
Data Information; Work of adhesion, Advance angle, Receding angle, Hysteresis,
drop volume, etc.,

-Surface Tension: Pendant drop method
Accuracy; ±0.1mN/m
Resolution; ±0.01mN/m
Range; 1~1000mN/m
Data Information; Drop volume, Surface tension

-Surface Free Energy:
(A) G.G.F.Y: (Accuracy ±0.1mN/m) (Resolution ±0.01mN/m) (Data Information,
Surface free Energy)
(B) Owens-Wendt (Accuracy ±0.1mN/m) (Resolution ±0.01mN/m) (Data
Information, Surface free energy, Dispersive value and Polar value)
(C) Lewis[Acid/Base] (Accuracy ±0.1mN/m) (Resolution ±0.01mN/m) (Data Information, Surface free Energy, Dispersive, Polar, Acid, base value

-Capture Speed: CCD, (Range 0~500FPS) (Data Information, Basic supplied is 500FPS)

-Machine Vision Resolution: (Range 640x480) (Data Information, Basic supplied is 640x480)

-Data Export Method: Two modes of Excel export, BMP, CSV file

-Data Save Method: Save as .SZX and Excel

-Sample Stage: Fixed Stage (no movement on X,Y axis)

-Device Dimension: Comes with Standard size (small and custom size is available)

-Power Consumption: 1.LED : 8.64W

-Power: 110/220V(50/60HZ)

8-inch Diameter Stainless Steel Frame, Stainless Steel Woven Wire Mesh, Certified Compliance to ASTM E11 Specifications, 90 microns or No.170
NOTE: For orders less than $300, there will be a minimum-order fee of $54.

8-inch Diameter Stainless Steel Frame, Stainless Steel Woven Wire Mesh, Certified Compliance to ASTM E11 Specifications, 850 microns or No.20
